Plastic Worm Drive - Ezyclamp - DIA 25-50mm - PA12 - Strap part of unit

Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6

Plastic Worm Drive - Ezyclamp - DIA 25-50mm - PA12 - Strap part of unit

Description

Designed and manufactured by HCL to the highest quality the Ezyclamp™ is a highly versatile Nylon Worm Drive Hose Clamp. The Ezyclamp™ is 12.7mm (½”) wide and available in 5 sizes covering a diameter range of 25mm (1”) to 150mm (6”). It is offered in a choice of materials: PA66 (Nylon 6.6.) for standard applications & PA12 (Nylon 12) for niche markets such as 5G telecommunications & Subsea.

Downloads

Product Specifications

  • Strap Length mm - inch 198 - 7.80
  • Can be used with-PA12 8mm Hex Screw or PA12 Wing
  • Diameter Range (A) mm25.0 - 50.0
  • Diameter Range (A) inch1.0 - 2.0
  • Band Width (B) mm - inch12.7 - 0.50
  • Band Thickness (C) mm - inch3.3 - 0.13
  • Clamp MaterialNylon 12
  • Flammability UL 94 V-2
  • Max long term operating temp125°C - 255°F
  • Max peak operating temp170°C - 340°F
  • Brand Ezyclamp
  • Manufactured By HCL Fasteners
  • Country of ManufactureUnited Kingdom
  • Hazardous Goods No
  • RoHS Compliant Yes

Features

  • Manufactured to DIN3017 Standard
  • Smooth Underside
  • Bevelled Edges Protect Hose
  • Exclusive Housing Design
$0.77

Original: $2.20

-65%
Plastic Worm Drive - Ezyclamp - DIA 25-50mm - PA12 - Strap part of unit—

$2.20

$0.77

Product Information

Shipping & Returns

Description

Description

Designed and manufactured by HCL to the highest quality the Ezyclamp™ is a highly versatile Nylon Worm Drive Hose Clamp. The Ezyclamp™ is 12.7mm (½”) wide and available in 5 sizes covering a diameter range of 25mm (1”) to 150mm (6”). It is offered in a choice of materials: PA66 (Nylon 6.6.) for standard applications & PA12 (Nylon 12) for niche markets such as 5G telecommunications & Subsea.

Downloads

Product Specifications

  • Strap Length mm - inch 198 - 7.80
  • Can be used with-PA12 8mm Hex Screw or PA12 Wing
  • Diameter Range (A) mm25.0 - 50.0
  • Diameter Range (A) inch1.0 - 2.0
  • Band Width (B) mm - inch12.7 - 0.50
  • Band Thickness (C) mm - inch3.3 - 0.13
  • Clamp MaterialNylon 12
  • Flammability UL 94 V-2
  • Max long term operating temp125°C - 255°F
  • Max peak operating temp170°C - 340°F
  • Brand Ezyclamp
  • Manufactured By HCL Fasteners
  • Country of ManufactureUnited Kingdom
  • Hazardous Goods No
  • RoHS Compliant Yes

Features

  • Manufactured to DIN3017 Standard
  • Smooth Underside
  • Bevelled Edges Protect Hose
  • Exclusive Housing Design
